Henwi HWAM-100L Extraction Machine Herbal Plant Flower Essential Oil Heating Extracting Device
Henwi HWAM-100L Extraction Machine Herbal Plant Flower Essential Oil Heating Extracting Device
Regular price
$8,300.00 USD
Regular price
Sale price
$8,300.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
1. Introduction
Since essential oils are insoluble in water, essential oils or other volatile compounds can be extracted from aromatic plants using traditional steam distillation methods.
The main functions of this style are heating and extraction.
The main functions of this style are heating and extraction.
Processing step:
1. Putting fresh plant/flower & pure water into tank.
2. Heating tank.
3. Opening the valve to allow steam and evaporated essential oil to enter the condenser.
4. Separating essential oil and water through oil-water separator.
5. Getting essential oil.
2. Specification
Extraction Machine with Heater
| 1 | Power supply | 380V/50Hz/3phase |
| 2 | Effective volume | 100L |
| 3 | Heating area | 0.9m㎡ |
| 4 | Condensing area | 0.95㎡ |
| 5 | Heating power | 12KW |
| 6 | Temperature range | 40-100°C |
| 7 | Heating jacket temperature | Max. 100℃ |
| 8 | Heating jacket pressure | 0.3 Mpa |
| 9 | Material | SUS304 |
| 10 | Dimension | 1550*900*1800mm |
| 11 | Weight | 350KG |
| 12 | Electric parts | Delixi, Schneider |
| 13 | Extraction rate | 1%~3% |
3. Applications
(1) Aromatic Oils Extraction: Ideal for extracting essential oils from flowers, leaves, and stems of aromatic plants.
(2) Herbal Medicine: Suitable for extracting essential oils and active compounds from medicinal herbs.
(2) Cosmetics Industry: For extracting natural oils used in cosmetics and skincare products.
(4) Pharmaceutical Industry: Essential oils extracted using this equipment are used in various pharmaceutical formulations.
(6) Food and Beverage: Extracting oils from plants used in flavoring and scenting food products.
(6) Environmental and Natural Therapy: Used for producing essential oils for aromatherapy and relaxation treatments.
