The powder screw feeder is a device used to transport powdered or granular materials (such as powder, granules, pellets, etc.) from one location to another. It is widely used in food, chemical, pharmaceutical, building materials and other industries. This feeder uses the rotation of the screw to transport the powder material from the silo or storage hopper to the designated receiving equipment or container. It is usually used in automated production lines to improve production efficiency and reduce manual labor.
(1) Food industry: milk powder, sugar powder, seasoning, coffee powder, starch, etc. (2) Chemical industry: fertilizers, pigments, plastic particles, detergent powder, etc. (3) Pharmaceutical industry: pharmaceutical powder, health care powder, etc. (4) Building materials industry: cement, gypsum powder, dry mortar, etc. (5) Daily chemical industry: laundry detergent, shampoo raw materials, cosmetic powder, etc.
2. Specification
1
Power supply
380V/50Hz
2
Feeding way
Auger screwing feeding
3
Feeding pipe diameter
133mm
4
Machine material
SUS 304 (can be customized SUS316L)
5
material hopper
150L
6
Speed
2.2m³-4m³ per hour
7
Power
2.2KW
8
Weight
150KG
9
Dimension
2300*900*2200mm
10
Pipe angle
45° (Can customize 30°~60°)
3. Feature
(1) Dual motors: The feeding motor and the vibration motor are separated and controlled by their own switches. (2) The material box vibrates with adjustable amplitude, and the material is not easy to bridge, and the material adaptability is strong. (3) The material box and the auger are separated, with a reasonable structure and convenient loading and unloading. The unique dust-proof design prevents the bearings from being contaminated by dust. (4) No dead angle, easy to clean the residual material. The corner connection is an arc transition, the spiral can be unloaded in the reverse direction, there is a gate unloading at the lower end of the material tube, and the entire spiral can be easily taken out, etc.
