1. Working Principle
(1) Initial weighing: There is an independent electronic weighing system under each filling head. The machine records the weight of the empty container before starting filling, and uses this as a reference.
(2) Material filling and weighing: When the system starts filling, the material is conveyed from the tank to the filling head, and then flows into the container through the filling head. The system monitors the weight change of the container in real time during the filling process and accurately controls the flow of the material.
(3) Independent control: The two filling heads of the machine are each equipped with an independent weighing system, which can fill two containers at the same time, or work alternately as needed, and flexibly adjust production efficiency.
(4) Fast filling stage: In the initial stage, most of the material is quickly injected into the container to improve efficiency.
(5) Slow filling stage: When approaching the target weight, the filling speed gradually slows down to avoid overfilling and ensure accuracy.
2. Application
Please inquire us if you're not sure whether this machine can process your product or not.
This machine series is suitable for filling bottling packing liquid cosmetics & food & pharmaceutical & chemical products into big barrel or drum or other containers.
Like shampoo, liquid soap, disinfectant, liquid laundry detergent, lubricant, engine oil, butter, dishwasher paste, dish soap, car wash water, glass cleaner, hand sanitizer, water base paint, thinner water, liquid fertilizer, liquid pesticide, liquid insecticide, liquid chemical, etc.
3. Specification
1
|
Qty of filling head
|
1 head
|
2 heads
|
2
|
Filling range
|
1KG-20KG
|
1KG-20KG
|
3
|
Filling speed
|
About 200~300 barrels/hour
|
About 300~500 barrels/hour
|
4
|
Filling accuracy
|
±10g
|
±10g
|
5
|
Material
|
304 stainless steel
|
304 stainless steel
|
6
|
Program controller
|
Touch panel screen & PLC control
|
Touch panel screen & PLC control
|
7
|
Air pressure
|
0.4 -0.6mpa
|
0.4 -0.6mpa
|
8
|
Power
|
1.5kw
|
2.2kw
|
9
|
Material feeding method
|
Direct suction
|
Direct suction
|
11
|
Pump type
|
Gear pump
|
Gear pump
|
13
|
Electrical components
|
Delixi/CHNT/Schneider
|
Delixi/CHNT/Schneider
|
14
|
PLC
|
MAGS
|
MAGS
|
15
|
Touch screen
|
MAGS
|
MAGS
|
19
|
Pneumatic components
|
AirTAC
|
AirTAC
|
20
|
Machine size
|
800*800*1550 (mm)
|
1100*800*1550 (mm)
|
21
|
Weight
|
150 (KG)
|
180 (KG)
|
22
|
Power supply
|
220V/50Hz
|
220V/50Hz
|
