Henwi HWSM-Single Lane Liquid Sachet Filler Sealer Water Juice Honey Sauce Shampoo Cream Syrup Filling Packing Machine
Henwi HWSM-Single Lane Liquid Sachet Filler Sealer Water Juice Honey Sauce Shampoo Cream Syrup Filling Packing Machine
Regular price
$3,900.00 USD
Regular price
Sale price
$3,900.00 USD
Unit price
/
per
1. Introduction
Single-row roll film bag forming liquid filling and sealing machine is a kind of equipment that automatically forms, fills and seals roll film bags, and is mainly used for packaging liquid materials.
Working step: (1) Film roll placement and transportation ➡ (2) Bag forming ➡ (3) Longitudinal heat sealing ➡ (4) Horizontal heat sealing and cutting ➡ (5) Liquid filling ➡ (6) Bag sealing ➡ (7) Finished product output
Applicable sachet material: plastic, PP, PE, PET, BOPP, kraft bag, laminated sachet, etc.
Applicable filling material: liquid, water, sauce, juice, oil, jam, honey, cream, shampoo, ketchup, mayonnaise, etc.
2. Specification
1 |
Machine material
|
SUS304
|
2 |
Bag size range
|
L:30-160mm; W:30-100mm
|
3 |
Speed
|
20-40 (PCS/Min)
|
4 |
Filling volume
|
1-50ml
|
5 |
Power
|
220V 50HZ 1.1KW
|
6 |
Weight
|
200KG
|
7 |
Machine size
|
650*750*1580mm
|
8 |
Packaging material
|
Paper/PE, PET/PE, PET/AL/PE, BOPP, etc.
|
9 |
Sealing type
|
3 side seal / 4 side seal / Back seal
|
10 |
Applications
|
liquid, water, sauce, jam, honey, cream, juice, shampoo, ketchup, mayonnaise, etc.
|
