Henwi HWTM-HS Automatic Soft Plastic Tube Filling Sealing Machine PET Tube Filler And Heating Sealer

1. Introduction

Please inquire us if you're not sure whether this machine can process your product or not.

This machine series is suitable for filling and sealing liquid cosmetics & food & pharmaceutical & chemical products into soft tube containers, like plastic tube, aluminum tube, and aluminum-plastic laminated tube.

Applicable for toothpaste, body cream, skincare lotion, conditioner, concealer, ointment, unguent, jam, food paste, pie, condensed milk, dressing, butter, skin jelly, body gel, hand sanitizer, paint, glue, sunscreen, face cleaner, balm oil, moisturizer, etc.

2. Specification

1	Qty of filling head	1 head
2	Filling range	6-60ML; 10-120ML; 25-250ML; 50-500ML; Customized
3	Filling speed	About 30~70 tubes/min
4	Filling accuracy	±1%.
5	Functions	Filling, Sealing, Coding, Trimming
6	Sealing method	Heating Sealing
7	Sealing shape	Flat tail, curved tail, special-shaped tail
8	Number of work positions	12
9	Applicable tube diameter	12-50mm
10	Applicable tube height	50-250mm
11	Automatic detection function	No work without hose
12	Material	304 /316 stainless steel
13	Program controller	Touch panel screen & PLC control
14	Air pressure	0.6 -0.8mpa
15	Power	3kw
16	Capacity of material tank	40L
17	Protective device	Equipped with safety device Overload protection
18	Pump type	Piston pump
19	Frequency inverter	Mitsubishi
20	Electrical components	Delixi/CHNT/Schneider
21	PLC	Mitsubishi
22	Touch screen	Mitsubishi
23	Servo system	Hechuan
24	Sensor	Banner/OMRON/Panasonic
25	Motors	ZD/Beide
26	Pneumatic components	AirTAC
27	Heater & controller	SWITZERLAND & DELTA (400F)
28	Machine size	2620×1250×1980 (mm)
29	Weight	1100 (KG)
30	Power supply	380V/50Hz

3. Production Line

(1) Water Purification Treatment Device

(2) Raw Water Tank & Pure Water Tank

(3) Vacuum Homogenizing Heating Mixer Machine

(4) SUS Storage Tank

(5) Automatic Tube Filling Sealing Machine

(6) Other Accessory Machine

4. Processing Step
