Henwi HWTM-US Automatic Laminated Tube Filling Sealing Machine Composited Tube Filler And Ultrasonic Sealer

Henwi HWTM-US Automatic Laminated Tube Filling Sealing Machine Composited Tube Filler And Ultrasonic Sealer

Regular price $13,500.00 USD
Regular price Sale price $13,500.00 USD
Sale Sold out
Shipping calculated at checkout.

1. Introduction

Please inquire us if you're not sure whether this machine can process your product or not.

This machine series is suitable for filling and sealing liquid cosmetics & food & pharmaceutical & chemical products into soft tube containers, like plastic tube, aluminum tube, and aluminum-plastic laminated tube.

Applicable for toothpaste, body cream, skincare lotion, conditioner, concealer, ointment, unguent, jam, food paste, pie, condensed milk, dressing, butter, skin jelly, body gel, hand sanitizer, paint, glue, sunscreen, face cleaner, balm oil, moisturizer, etc.

2. Specification

1
Qty of filling head
1 head
2
Filling range
6-60ML;
10-120ML;
25-250ML;
50-500ML;
Customized
3
Filling speed
About 20~30 tubes/min
4
Filling accuracy
±1%.
5
Functions
Filling, Sealing, Coding
6
Sealing method
Ultrasonic Sealing
7
Ultrasonic frequency
20 kHz
8
Sealing shape
Flat tail, curved tail, special-shaped tail
9
Number of work positions
10
10
Applicable tube diameter
16-50mm
11
Applicable tube height
50-250mm
12
Automatic detection function
No work without hose
13
Material
304 /316 stainless steel
14
Program controller
Touch panel screen & PLC control
15
Air pressure
0.6 -0.8mpa
16
Power
2.6kw
17
Capacity of material tank
30L
18
Protective device
Equipped with safety device
Overload protection
19
Pump type
Piston pump
20
Frequency inverter
Delta
21
Electrical components
CHNT/Schneider
22
PLC
HCFA
23
Touch screen
Weinview
24
Servo system
Hechuan
25
Sensor
Panasonic
26
Motors
ZD/Beide
27
Pneumatic components
AirTAC
28
Machine size
1590*1400*1650 (mm)
29
Weight
450 (KG)
30
Power supply
220V/50Hz


3. Production Line

(1) Water Purification Treatment Device

(2) Raw Water Tank & Pure Water Tank

(3) Vacuum Homogenizing Heating Mixer Machine

(4) SUS Storage Tank

(5) Automatic Tube Filling Sealing Machine

(6) Other Accessory Machine

4. Optional Tail Shape
